2 Years Free update XTOOL X100 PAD Plus IMMO & Key Programmer Add All Systems Diagnostic 28+ Services ABS Bleed/Oil Reset/Throttle Injector Coding/BMS Reset

Product Description

XTOOL X100 PAD Plus IMMO & Key Programmer Add All Systems Diagnostic

Top 10 Reasons to get the XTOOL X100 PAD Plus:

1. Comprehensive Immo & Key Programming
2. OE-Level All Sytems Diagnostic, performs OE-level diagnostics to read/erase DTCs, view data stream, freeze frame, read ECU info.
3. Advanced 28+ Service Functions, Upgraded Verison of X100 PAD,
4. Add Live data graphing
5. No activation code requiring anymore, easier to use.
6. X100 PAD PLUS CAN NOT perform Mileage Correction function or Bi-directional control
7. X100 PAD PLUS do not work for VW/BENZ/BMW specific vehicles or for Toyota smart key all key losst.
8 2 Years Software Update, no limited after 2 years for working
9. Multiple Languages: English, Spanish, Portuguese, French, Japanese, German, Polish, Russian, Italian, Korean, Dutch, Swedish, Chinese. Just send the Serial Number to change
10. Check the functions and car list here



What is the difference between X100 PAD and X100PAD PLUS?

1.X100 PAD PLUS Can not work for Instrument Cluster but the x100 pad can support mileage.
2.X100 PAD PLUS Can works for all systems diagnostic functions but the x100 pad can't
3.X100 pad plus with more special Functions including the full systems OBD2 diagnostic



IMMO Key Programming:

Read PIN, Add Transponder/Smart Key, Disable Lost Keys, Remote Learning, Make Dealer Key/All-Key-L~st, IMMO ECU Reset/Coding,IMMO Data Backup, Key Programming, Key Learning/Key Matching, EEPROM Read & Write, etc.

Warmly Notice: X100 PAD PLUS key programming function can not work for Benz, or for Most BMW, or for Audi/VW, or for Toyota smart key all key losst, or for Chrysler read pin (need XTOOL IK618+adapter).

All System Diagnostics:

The Diagnostics application enables a data link to the electronic control system of the test vehicle for vehicle diagnosis. The application performsfunctional tests, retrieves vehicle diagnostic informationsuch as trouble and event codes and live data for various vehicle control systems, such asABS, SRS, Engine, Transmission, Brake System, Emission System, Fuel system, Light system, Wiper Systemetc.

28+ Special Functions:

Oil Reset, EPB, BMS Reset, Immo/Key Programming, Throttle Relearn, SAS Adjustment, EEPROM Adapter, Refresh Hidden Function, Injector Coding, ABS Bleeding, Tyre Pressure Reset, Performance Tire Upgrade, Gearbox Match, Headlight, Air Suspension, Window Initialization, Seat Configurations, Airbag Repair, Cylinder, Disable Transportation, Crankshaft Resync

Advanced IMMO/Key Programming/Key Coding(X100 PAD Plus Diagnostic Tablet + EEPROM Adapter)

Read PIN+Add Transponder/Smart Key+Disable Lost Keys+Remote Learning+Make Dealer Key+IMMO ECU Reset/Coding+IMMO Data Backup+Program Keys fobs+EEPROM Read & Write, etc.

EEPROM Adapter: Used to read, write and backup the EEPROM chip inside the immobilizer module. Through this adapter you can get access to the IMMO data, pin code, etc.

NOTE:

1. CAS4/CAS4+ can learn keys via OBD. *When working on EWS2/3, you'll need to disassemble the immobilizer module.
2. X100 PAD PLUS CAN'T support pull pin codes For Dodge Ram 2013-2018 .
3. X100 PAD PLUS CAN'T support pull pin codes For Dodge Charger/Challenger/300C 2015-2018 .
4. X100 PAD PLUS CAN'T support read pin codes from OBD for FCA Group(Fiat/Chrysler/Dodge/Jeep), via VPW protocol.

If you belong to the above vehicles please choose InPlus IK618(B098N91FPR) or X100 MAX(B09GLTF4X7).

MOST USEFUL SERVICE FUNCTIONS

Oil Reset: Reset service intervals after oil change and turn off the oil light.
EPB Reset: Reset brake pads after replacement of brake system.
BMS Reset: Register the new battery to the ECU after replacement.
Throttle Relearn: Enables you to make initial settings to throttle to adjust the amount of air intake.
EEPROM Adapter: Used to read, write and backup the EEPROM chip inside the immo~bilizer module.
Injector Coding: Coding injectors after replacement.
ABS Bleeding: Perform ABS Brake Bleed function to cycle the ABS pump to bleed the air out of the ABS.
Gearbox Match: Reset the adaptive shifting points in your automatic Transmission Control Unit.
Headlight: Initialize the adaptive headlight system.
Air Suspension: Calibrate the suspension height.
Window Initialization: Match the windows to restore the initial memory of the ECU and restore the power window.
Airbag Repair: Allows you resets the airbag data to clear the airbag collision/crash data.

OE-Level Full Systems Diagnostic

XTOOL X100 PAD PLUS diagnostic scan tool can access the electronic control unit (ECU) of various vehicle control systems, including the engine, transmission, antilock braking system (ABS), airbag system (SRS), and read ECU information, read and clear DTC and check living data and freeze frames.

What Updates have we made in 2023 Newest Upgraded Version of XTOOL X100 PAD PLUS?

✔️1. Newest APP above V4.24.2 optimize user experience and improve software issues.
✔️2. Simplified key programming operation menu.
✔️3. Add Live data graphing( Need to update the newest software and reboot the APP).
✔️4. Newest User Manual can be found on Product guides and documents on the page(More detailed introduction to help you use the scanner).

More optimization are coming soon!


• Live Data Graphing: Allows you to view the live PID(parameter identification data) data of vehicle’s computer module(s) in text, graph to check the status of various sensors.
• Wide Vehicles Coverage: X100PAD PLUS can access all vehicle systems of 65+ makes, 140+ brands, and 10000+ models to perform OE level diagnostics and IMMO key programming.
• Auto VIN SCAN for Quick Diagnosis: Just need one click, you can scan your car’s detailed version information, also all diagnostic trouble co*des and live data stream, freeze frame of full electrical control units. NOTE: Auto VIN feature does NOT work on all cars. You can always navigate your vehicle manually.
• Easy Report Printing: X100PAD PLUS auto diagnostic scan tool enables diagnostic tech or mechanics to generate diagnostic reports before and after car diagnostics and maintenance services for comparison or sharing with customers by printing it out or sending it to customers via PDF. Note: For tech assistance to set up printer please consult us via messages or Q/A.



item name	X100 PAD  PLUS	X100 PAD 3	IK618	X100 MAX
OE Full Systems Diagnostics	✓	✓	✓	✓
Bi-Directional Controls		✓	✓	✓
Battery Capacity	4000mAh	10,000mAh	5,000mAh	10,000mAh
Services	28+ Services	38+ Services	31+ Services	35+ Services
Display	7" Touch Screen with 1024*700 Resolution	8" Touch Screen with 1024*768 Resolution	7" Touch Screen with 1024*768 Resolution	9.7" Touch Screen with 1024*768 Resolution
Add new key fobs/remote keys for specific vehicles	✓	✓	✓	✓
Key Programmer Accessories	EEPROM Adapter	KC100+EEPROM Adapter	KC100+EEPROM Adapter	KC501+EEPROM Adapter
Pull Pin Code For FCA Group(Fiat/Chrysler/Dodge/Jeep)		✓	✓	✓
Software Update	2-Year Free	2-Year Free	2-Year Free	2-Year Free



XTOOL X100 PAD Plus Parameters:

Monitor：320*480 dpi TFT color display screen
Working Voltage：9V-18V
Working Temperature：-10°C-60°C
Storage Temperature：-20°C-70°C
Appearance Size：93*33*200mm(LxWxH)

XTOOL X100 PAD Plus Package List:

Accessories
Plastic Box
Main Units
X100PAD PLUS TABLET
Power Adapter 12V 1A
Main Cable
Micro USB Cable
US Power Adapter
EU Power Adapter
Test Connectors
Honda-3
OBDII-16
KIA/HYUDAI-10
KIA-20
EEPROM ADAPTER
